LANCOM 1930EF

Multi-WAN SD-WAN gateway with fiber and Gigabit Ethernet

As a multi-WAN SD-WAN gateway, the LANCOM 1930EF flexibly offers various Internet connections on one device for the site networking of medium-sized and large companies. Any external DSL or cable modems can be connected via Gigabit Ethernet. With the connection to fiber optic lines via an optional module, you also benefit from high-speed Internet even with data-intensive traffic. Intelligent load distribution across two Internet lines using load balancing increases the available bandwidth and reduces the network load. With the LANCOM Management Cloud (LMC), you centralize the management of the LANCOM 1930EF, ensure consistent and secure network management, and benefit from security "Engineered in Germany".

Technical features

  • SD-WAN – incl. zero-touch deployment and Auto-VPN via the LANCOM Management Cloud
  • Multi-WAN – high-speed Internet via fiber optics (GPON and AON modules available separately) and Gigabit Ethernet for connection of external modems (1x WAN Ethernet), 1x SFP/TP combo
  • Load balancing for the active/active operation of several Internet lines and maximization of the available bandwidth
  • Professional telephony features thanks to integrated LANCOM VCM (Voice Call Manager) & SBC (session border controller)
  • 25 simultaneous IPsec VPN connections (100 optional)
  • Network virtualization with up to 64 networks on one device (ARF)
  • Full-metal housing with front-facing connections and integrated 230V power supply unit for mounting in a 19" rack
  • Maximum future compatibility, reliability, and security "Engineered in Germany"

Highlights

LANCOM SD-WAN – Next-level networking

With LANCOM SD-WAN you can manage and monitor your entire corporate network centrally, cost-effectively, quickly, and stress-free! In combination with the LANCOM Management Cloud, the SD-WAN gateway gives you all the options for an automated setup of secure VPN connections (Auto-VPN) between sites, including network virtualization. Highlight features such as High Scalability VPN (HSVPN) and Advanced Mesh VPN offer you a significant plus in scalability and efficiency for a large number of branches and applications. Furthermore, if multiple WAN connections are defined, they are automatically operated in active/active mode (load balancing), thereby increasing the available total bandwidth. With Dynamic Path Selection and Dynamic Traffic Steering, applications are also dynamically routed via the best connection at any given time.

Learn more about LANCOM SD-WAN

Powerful Gigabit multi-WAN & load balancing

With the LANCOM 1930EF, you can flexibly use a wide variety of Internet connections on one device: The gateway can be connected directly to a fiber optic line (FTTH) via the SFP/TP combo port and separately available SFP module (GPON / AON). In addition, the SD-WAN gateway offers high flexibility via Gigabit Ethernet for connecting external modems. With the parallel use of several Internet lines (load balancing: active/active), the LANCOM 1930EF also ensures ideal load distribution of the data volume and a further increase in the bandwidth provided.

Advantages

High Scalability VPN (HSVPN)

The ongoing rise of digitalization, greater diversity of applications, and higher data volumes demand powerful, state-of-the-art networks. High Scalability VPN significantly improves the extensibility and efficiency of your architecture. Where previously each individual…

The ongoing rise of digitalization, greater diversity of applications, and higher data volumes demand powerful, state-of-the-art networks. High Scalability VPN significantly improves the extensibility and efficiency of your architecture. Where previously each individual application required a separate VPN tunnel, HSVPN bundles any number of networks into a single VPN tunnel and transports them collectively to the remote site – with each network remaining secure and strictly separated from the others. The advantage for your business: Considerably fewer VPN tunnels are required, and recovery times are much faster in a failover event. And if you need more VPN tunnels, the LANCOM VPN 100 option is available, allowing you to securely connect up to 100 locations or external employees to the corporate network at the same time.

Security with ARF, VLAN, and inspection firewall

Equipped with a stateful inspection firewall, the LANCOM SD-WAN gateway protects the entire network with functions such as intrusion prevention and denial of service protection. Logical network segmentation allows you to…

Equipped with a stateful inspection firewall, the LANCOM SD-WAN gateway protects the entire network with functions such as intrusion prevention and denial of service protection. Logical network segmentation allows you to define individual security settings and access rights according to the requirements of the user groups, and to divide your infrastructures and applications into different areas. This network segmentation using ARF (Advanced Routing and Forwarding) and VLAN (Virtual Local Area Network) ensures that your enterprise network as a whole remains protected, even if a network segment is compromised.

Techpaper: Advanced Routing and Forwarding

Secure communication via VPN

With virtual private networks (VPN), you use the public medium of the Internet as a communication path and secure the connection in such a way that the communication still remains completely inaccessible to external parties. This SD-WAN gateway…

With virtual private networks (VPN), you use the public medium of the Internet as a communication path and secure the connection in such a way that the communication still remains completely inaccessible to external parties. This SD-WAN gateway offers you 25 integrated IPSec VPN channels for secure encryption, so that the protection of internal company data is always guaranteed when connecting mobile employees, home offices, or branch offices. With the LANCOM VPN Option, you can also upgrade the device to up to 100 VPN channels, so that the infrastructure can easily grow with your needs without additional hardware.

Maximum future-proofing and digital sovereignty

As an established German manufacturer of IT network solutions, LANCOM stands for reliability and know-how. Software and hardware development as well as production take place primarily in Germany, as does the hosting of…

As an established German manufacturer of IT network solutions, LANCOM stands for reliability and know-how. Software and hardware development as well as production take place primarily in Germany, as does the hosting of the network management.  Special attention is given to providing trusted solutions with outstanding security features. Another important security characteristic of the products is that they are free from backdoors, as awarded by the German Federal Ministry of Economy with the quality seal “IT Security made in Germany”. All devices are always equipped with with hardware that is dimensioned for the future. Even across product generations, updates to the LANCOM operating system family are available several times a year, free of charge. his guarantees a long service life while staying technically up to date, which represents a true protection of your investment. In addition, LANCOM infrastructures are easily scalable thanks to maximum compatibility.

Learn more about digital sovereignty

Connectors

Front view LANCOM 1930EF
Click on the device illustration to download the Visio shape.

Typical application scenarios

Application scenario with one client

A client is connected to the Internet via the multi-WAN SD-WAN gateway in active/active mode (load balancing). Load balancing is used to distribute the load of the data volume in the network across Internet lines used in parallel. In this way, data connections are distributed evenly over (at least) two lines and the individual bandwidths of the lines are added together. In this scenario, the load balancer integrated in the SD-WAN gateway decides whether to use Internet line 1 or Internet line 2, depending on the load. Even if one line fails, the connection via the other line is always secured.

Application scenario with two or more clients

Several clients are connected to the Internet via the multi-WAN SD-WAN gateway (two external modems for any connections). Now, for example, two clients with a load balancer integrated in the router can work in parallel at the same download speed, as this enables the data load to be distributed over both Internet lines (1 & 2). This enables maximum utilization and consequently an enormous increase in network efficiency.

Application scenario with VPN load balancing

With the integrated load balancer, IKEv2 VPN connections can also be conveniently combined into a load balancer network. Regardless of whether the network is realized with a LANCOM SD-WAN gateway, a LANCOM SD-WAN central site gateway (e.g. LANCOM ISG-5000), or the LANCOM vRouter, the load is better distributed and the data traffic is automatically taken over if one connection fails. This significantly increases the VPN bandwidth for multiple clients.


Further information & news

Options & accessories

¹ Compatible transceiver modules: SFP-SX-LC1, SFP-SX2-LC1, SFP-LX-LC1, SFP-CO1, SFP-BiDi1550-SC1, SFP-AON-1, SFP-GPON-1, and SFP-XGSPON-1

Service & support

Included services

  • 3 years replacement service (return & replace)
  • Technical manufacturer support for LANcommunity partners and end customers with LANcare Direct or LANcare Premium Support

Optional services

Click below to get more information as well as the item numbers for convenient additional booking.

Click below to get more information as well as the item numbers for convenient additional booking.

Notes: Times are given in hours (h) or minutes (m) per days (d). The products are available for different service categories (S, M, L, XL) as well as validity and can be easily added using the item numbers.


  • LANcare Direct 10/5
    Direct manufacturer support and security updates for 1, 3, or 5 years
    Availability: 10h / 5d, first reaction time: 2h (priority 1) up to 4h (priority 2)
    Item numbers: S: 10740 / 10741 / 10742, M: 10743 / 10744 / 10745, L: 10746 / 10747 / 10748, XL: 10749 / 10750 / 10751

  • LANcare Direct Advanced 10/5
    Direct manufacturer support, security updates, and advance relacement for 1, 3, or 5 years
    Availability: 10h / 5d, first reaction time: 2h (priority 1) up to 4h (priority 2), delivery: NBD
    Item numbers: S: 10764 / 10765 / 10766, M: 10767 / 10768 / 10769, L: 10770 / 10771 / 10772, XL: 10773 / 10774 / 10775

  • LANcare Direct 24/7
    Direct manufacturer support incl. 24/7 emergency hotline and security updates for 1, 3, or 5 years
    Availability: 24h / 7d, first reaction time: 30m (priority 1) up to 4h (priority 2)
    Item numbers: S: 10752 / 10753 / 10754, M: 10755 / 10756 / 10757, L: 10758 / 10759 / 10760, XL: 10761 / 10762 / 10763

  • LANcare Direct Advanced 24/7
    Direct manufacturer support incl. 24/7 emergency hotline, security updates, and advance relacement for 1, 3, or 5 years
    Availability: 24h / 7d, first reaction time: 30m (priority 1) up to 4h (priority 2), delivery: NBD
    Item numbers: S: 10776 / 10777 / 10778, M: 10779 / 10780 / 10781, L: 10782 / 10783 / 10784, XL: 10785 / 10786 / 10787

  • LANcare Basic
    Security updates until EOL as well as 5 years replacement service
    Availability: 8h / 5d, shipment: 5 days
    Item numbers: S: 10720, M: 10721, L: 10722, XL: 10723

  • LANcare Advanced
    Security updates until EOL as well as 5 years advance relacement
    Availability: 8h / 5d, delivery: NBD
    Item numbers: S: 10730, M: 10731, L: 10732, XL: 10733

  • LANcare Premium Support 10/5
    Manufacturer support and security updates for projects
    Availability: 10h / 5d, first reaction time: 2h (priority 1) up to 4h (priority 2)
    (on request)

  • LANcare Premium Support 24/7
    Manufacturer support incl. 24/7 emergency hotline and security updates for projects
    Availability: 24h / 7d, first reaction time: 30m (priority 1) up to 4h (priority 2)
    (on request)
